The Jazzy® Elite ES delivers a reliable blend of power, performance and style. In-line, front-wheel drive technology gives the Elite ES excellent stability and maneuverability for solid performance indoors and out.
Features:
In-line, front-wheel drive technology
40 amp, PG GC 3 controller
Simple main frame design for easy serviceability
Comfort high-back seat with headrest
Jazzy® Armor® controller guard to protect from daily wear and tear
Basic Jazzy Armor shroud decals
Specifications:
| Model | Jazzy Elite ES |
| Weight Capacity | 300 lbs. |
| Turning Radius | 24.75" |
| Width | 22.75" |
| Length | 34.75" |
| Maximum Speed* | Up to 4 mph |
| Ground Clearance | 1.5" |
| Front Wheels | 3" solid anti-tips |
| Drive Wheels | 9" solid |
| Rear Wheels | 6" solid casters |
| Drivetrain | Two-motor, in-line, front-wheel drive |
| Braking System | Regenerative and electro-mechanical |
| Suspension Type | Limited |
| High-Back Seating | 20"W x 20"D (max. dimensions) |
| High-Back Seat-to-Floor Range | 21.5" - 23.5" |
| Specialty Seating | 20"W x 20"D (max. dimensions) |
| Specialty Seat-to-Floor Range | 16.5" - 18.5" |
| Synergy Seating | 20"W x 20"D (max. dimensions) |
| Synergy Seat-to-Floor Range | 17.25" - 19.25" |
| Standard Electronics | 40A, PG GC3 |
| Battery Size | 12 volt, U-1 (2 Required) |
| Standard Battery Charger | 3A, off-board |
| Per-Charge Range* | Up to 15 miles |
| Battery Weight | 24.5 lbs. each |
| Base Weight | 68.5 lbs. |
| Standard Seat Weight | 43 lbs. (comfort high-back) |
| Standard Seat Size | 18" x 18" |
| Medicare Code Coverage | Group 2: Standard, Portable (K0822/K0823) |
5-year limited warranty on frame;
13-month limited warranty on electronics;
13-month limited warranty on drive motors
